Our Intelligent Chargers feature internal circuitry which detects the battery type, current battery charge, overall battery condition, and automatically responds to optimize charging!
4.0 Amp Intelligent Battery Charger
For Battery Types: Lithium Iron-Phosphate (LiFePo4), LPF, SLA, AGM, Maintenance Free, Flooded, Wet Cell, VRLA, Gel, Lead-Acid, Vented, Deep Cycle
Microprocessor Controlled
Input Voltage: 100-140V AC
Input Current: 0.9A
Output Voltage: 6V Or 12V (Nominal)
Output Current: 4A (High) 1A (low)
AC Cord Length: 6ft
DC Cord Length: 6ft
Protections: Short Circuit, Reverse Polarity
9-Stage Charging:
Primary Evaluation: The Charger Runs A Diagnostic Test On The Battery's Condition, Charge And Overall Health
Recovery Charge: The Charger Will Begin To Restore A Deeply Discharged Battery. This Step Is Skipped IF The Battery Does Not Require It
Soft Start: A Slow Charge Current Is Applied That Slowly Ramps Up To Protect The Battery And Optimize Charging
Pulse Cycle: This Step Initiates To Help Reduce Sulfation Build-Up On Plates That May Be Inhibiting The Battery's Ability To Reach Full Capacity
Reconditioning Cycle: Prepares Battery For Bulk Charging And Finalizes The Recovery Charge
Bulk Charging: The Charger Identifies The Battery And Its Needs Then Applies A High Voltage/Amperage Charge To Do The Bulk Of The Charging
Absorption Charging: When The Battery Reaches 80% Capacity The Input Current Begins To Lower, Also Known As The Cooldown Period
Evaluation Diagnostic: The Last Diagnostic To Ensure The Battery Is At Optimal Health
Maintenance Charge: When The Battery Reaches 95% The Charger Will Continue To Apply A Steady Current Up To 100% And Continue To Monitor The Battery And Apply A Charge If It Detects Any Loss
Winter Charging Mode Help Maintain The Battery When The Temperature Drops Below 41°F (5°C)
Operating Temperature: 34°F - 140°F (1°C - 60°C)
Storage Temperature: 34°F - 140°F (1°C - 60°C)
Unit Size: 7.3" x 3.3" x 1.7"
Weight: 0.9lbs
Certifications: CE, BC
Sold Individually
Quality Made Product
