30 LED 5.5" Hybrid Combination Round Stop Turn Tail & Back Up Warning Light By Maxxima

30 LED 5.5" Hybrid Combination Round Stop Turn Tail & Back Up Warning Light By Maxxima

• 5.5" Hybrid Combination Round Stop Tail Turn LED Light

• Features 30 (12 Red, 9 White, 9 Amber) High Powered LEDs
• All-In-One S/T/T & Back-Up & Dual Color Amber White Flashing Warning
• Amber Turn For Trucks With Dedicated Turn Wire (4-wire S/T/T circuit)
• Flash Amber Only, White Only, Or Amber / White Dual Color
• Patented Hybrid Series with Lightning Optics
• US Patent No 8,009,364 8,052,313   8,717,679 B2
• Mounting Screws and Screw Caps Included
• Neoprene Gasket Attached
• 7 Blunt Cut Wires
• Polycarbonate Lens & Housing
• DOT FMVSS108 / CMVSS108 Compliant
• Voltage: 12.8VDC
• Amp Draw: 0.6A Max Amp (Stop + Warn)
• BU 0.2A, Tail 20mA, Stop 0.2A, Amber Turn 100mA, Warn 0.4A
• Dimensions: 5.5” W x 0.5” D
• Mounting: 3-Hole Flange Mount (3) 3/16” Holes
• Hole cutouts: 1-3/16” For Cable Exit
• Connector: 7 Leads Blunt Cut, 10”
• Legal Heading: R, I6 S2 T2, W-1
• DOT / SAE: J593, J2040, J2261, J595
• Sold Individually
• Quality Made Product

California Prop 65 WARNING: This product may expose you to a chemical known to the state of California to cause cancer and birth defects or other reproductive harm.

If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990
