Interstate-McBee Cummins ISX QSX Inframe Engine Kit M-4376178

$3,848.95

SKU:
69358
Shipping:
Calculated at Checkout
Frequently bought together:
  • Description


    Interstate McBee Cummins ISX QSX Inframe Engine Kit M-4376178

    *Please confirm that this Interstate McBee part # is needed for your engine before purchase. If the wrong kit is purchased a member from our team may contact you to help you with the correct item. Or you can call our sales team with your engine serial # and they'd be happy to assist you over the phone!

    *Image For Reference - Actual Components Received Will Vary Based On Engine Serial Number

    • Heavy Duty Inframe Kit
    • Fits Cummins ISX, ISX10, ISX15, QSX, QSX15, CM2250, & CM2350 Engines (Enter Engine Serial Number Above)
    • Direct Aftermarket Replacement For OEM #: 4376178, M-4376178, M4376178
    • Engine Specifications:
      • Cummins ISX15 (2010-2016)
        • Liter: 15
        • CID (Cubic-Inch Displacement): 912
        • Cylinders: L6
        • Bore: 5.3937" - 5.4000"
        • Stroke: 6.653"
        • Compression Ratio: 18:1
        • Firing Order: 1-5-3-6-2-4
      • Cummins QSX (1997-2016)
        • Liter: 15
        • CID (Cubic-Inch Displacement): 912
        • Cylinders: L6
        • Bore: 5.3937" - 5.4000"
        • Stroke: 6.653"
        • Compression Ratio: 18:1
        • Firing Order: 1-5-3-6-2-4
    • Tune-Up Specifications:
      • Oil Pressure At Idle: 20 PSI @ Idle 200 Degrees Fahrenheit
      • Intake Valve Lash: 0.014" Cold
      • Exhaust Valve Lash: 0.027" Cold
    • Includes:
      • (6) Cylinder Liner Kit
      • (6) Piston Kit
      • (1) Upper Engine Gasket Set
      • (6) ISX Connecting Rod Bearing
      • (1) ISX Main Bearing Set
      • (1) O-Ring Seal
      • (1) Pressure Relief Valve
      • (1) Oil Pan Gasket
    • Heavy Duty Engineered To Provide A Long Service Life
    • Skirt Type: Closed
    • Top Ring Location: Low
    • Top Land Diameter: Reduced or Large
    • Liner OD Size: 150mm
    • ISO 9001:2015 Certified With Design
    • AAR M-1003 Certified
    • Sold As A Kit
    • Quality Made Product

    There may be multiple listings on our site that fit the same model engine but due to the technical nature of engine kits, the correct application and fitment is decided by engine serial #. If it is determined that you will need a different engine kit and there is a price difference, a member of our team will contact you to see if you still wish to proceed. We will do our best to make the buying process as easy as possible for you!

    Providing engine parts, fuel injection parts, and gaskets for the diesel and gas industries since 1947, Interstate-McBee strives to provide quality and consistency in their products while offering the most extensive selection in the aftermarket. Following a meticulous manufacturing and remanufacturing process using only the best possible raw materials, all products are guaranteed to be consistent with their industry-leading standards.

    Any mention of OEM names or OEM product ID numbers/descriptions/model numbers is intended for identification purposes only and does not indicate that it is an OEM part.

    California Prop 65 WARNING: This product may expose you to a chemical known to the State of California to cause cancer and birth defects or other reproductive harm

    If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990

    *This product ships LTL Freight and the shipping quotes are based on commercial addresses only. If you need a quote to have this delivered to a residential address or farm, please call us so we can provide you with an accurate shipping price. Failing to provide a commercial address could result in delays with processing your order. Please refer to our Shipping Info section at the bottom of our website for more information.

  • Warranty Information

    Interstate-McBee General Warranty Policies

    Engine Components and Kits: Warranted against manufacturing defects for one year (1 yr.) or 100,000 miles, whichever comes first.
    Fuel Injectors, Pumps, and Components: Warranted against manufacturing defects for one year (1 yr.)

  • Reviews
  • Questions & Answers

Description


Interstate McBee Cummins ISX QSX Inframe Engine Kit M-4376178

*Please confirm that this Interstate McBee part # is needed for your engine before purchase. If the wrong kit is purchased a member from our team may contact you to help you with the correct item. Or you can call our sales team with your engine serial # and they'd be happy to assist you over the phone!

*Image For Reference - Actual Components Received Will Vary Based On Engine Serial Number

  • Heavy Duty Inframe Kit
  • Fits Cummins ISX, ISX10, ISX15, QSX, QSX15, CM2250, & CM2350 Engines (Enter Engine Serial Number Above)
  • Direct Aftermarket Replacement For OEM #: 4376178, M-4376178, M4376178
  • Engine Specifications:
    • Cummins ISX15 (2010-2016)
      • Liter: 15
      • CID (Cubic-Inch Displacement): 912
      • Cylinders: L6
      • Bore: 5.3937" - 5.4000"
      • Stroke: 6.653"
      • Compression Ratio: 18:1
      • Firing Order: 1-5-3-6-2-4
    • Cummins QSX (1997-2016)
      • Liter: 15
      • CID (Cubic-Inch Displacement): 912
      • Cylinders: L6
      • Bore: 5.3937" - 5.4000"
      • Stroke: 6.653"
      • Compression Ratio: 18:1
      • Firing Order: 1-5-3-6-2-4
  • Tune-Up Specifications:
    • Oil Pressure At Idle: 20 PSI @ Idle 200 Degrees Fahrenheit
    • Intake Valve Lash: 0.014" Cold
    • Exhaust Valve Lash: 0.027" Cold
  • Includes:
    • (6) Cylinder Liner Kit
    • (6) Piston Kit
    • (1) Upper Engine Gasket Set
    • (6) ISX Connecting Rod Bearing
    • (1) ISX Main Bearing Set
    • (1) O-Ring Seal
    • (1) Pressure Relief Valve
    • (1) Oil Pan Gasket
  • Heavy Duty Engineered To Provide A Long Service Life
  • Skirt Type: Closed
  • Top Ring Location: Low
  • Top Land Diameter: Reduced or Large
  • Liner OD Size: 150mm
  • ISO 9001:2015 Certified With Design
  • AAR M-1003 Certified
  • Sold As A Kit
  • Quality Made Product

There may be multiple listings on our site that fit the same model engine but due to the technical nature of engine kits, the correct application and fitment is decided by engine serial #. If it is determined that you will need a different engine kit and there is a price difference, a member of our team will contact you to see if you still wish to proceed. We will do our best to make the buying process as easy as possible for you!

Providing engine parts, fuel injection parts, and gaskets for the diesel and gas industries since 1947, Interstate-McBee strives to provide quality and consistency in their products while offering the most extensive selection in the aftermarket. Following a meticulous manufacturing and remanufacturing process using only the best possible raw materials, all products are guaranteed to be consistent with their industry-leading standards.

Any mention of OEM names or OEM product ID numbers/descriptions/model numbers is intended for identification purposes only and does not indicate that it is an OEM part.

California Prop 65 WARNING: This product may expose you to a chemical known to the State of California to cause cancer and birth defects or other reproductive harm

If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990

*This product ships LTL Freight and the shipping quotes are based on commercial addresses only. If you need a quote to have this delivered to a residential address or farm, please call us so we can provide you with an accurate shipping price. Failing to provide a commercial address could result in delays with processing your order. Please refer to our Shipping Info section at the bottom of our website for more information.
