Interstate-McBee Cummins ISM QSM M11 L10 Inframe Engine Kit M-4090008

$2,748.95

SKU:
69361
Shipping:
Calculated at Checkout
Frequently bought together:
  • Description


    Interstate McBee Cummins ISM QSM M11 L10 Inframe Engine Kit M-4090008

    *Please confirm that this Interstate McBee part # is needed for your engine before purchase. If the wrong kit is purchased a member from our team may contact you to help you with the correct item. Or you can call our sales team with your engine serial # and they'd be happy to assist you over the phone!

    *Image For Reference - Actual Components Received Will Vary Based On Engine Serial Number

    • Heavy Duty Inframe Kit
    • Fits Cummins ISM, QSM, M11, & L10 Engines (Enter Engine Serial Number Above)
    • Engine Specifications:
      • Cummins ISM (1999-2008)
        • Liter: 11
        • CID (Cubic-Inch Displacement): 659
        • Cylinders: L6
        • Bore: 4.9213" - 4.9250"
        • Stroke: 5.787"
        • Firing Order: 1-5-3-6-2-4
      • Cummins M11 (1991-2001)
        • Liter: 11
        • CID (Cubic-Inch Displacement): 661
        • Cylinders: L6
        • Bore: 4.9213" - 4.9250"
        • Stroke: 5.790"
        • Compression Ratio: 1-5-3-6-2-4
      • Cummins L10 (1985-1990)
        • Liter: 11
        • CID (Cubic-Inch Displacement): 611
        • Cylinders: L6
        • Bore: 4.9210" - 4.9270"
        • Stroke: 5.354"
        • Compression Ratio: 1-5-3-6-2-4
      • Cummins QSM (1995-2015)
        • Liter: 11
        • CID (Cubic-Inch Displacement): 659
        • Cylinders: L6
        • Bore: 4.9213" - 4.9250"
        • Stroke: 5.787"
        • Compression Ratio: 1-5-3-6-2-4
    • Tune-Up Specifications:
      • Cummins ISM (1999-2008)
        • Oil Pressure At Idle: 10 PSI Min at Idle
        • Oil Pressure: 40-50 PSI @ Rated Speed
        • Intake Valve Lash: 0.014" Cold
        • Exhaust Valve Lash: 0.027" Cold
      • Cummins M11 (1991-2001)
        • Oil Pressure At Idle: 10 PSI
        • Oil Pressure: 30 PSI Min @ 1200 RPM
        • Intake Valve Lash: 0.014" Cold
        • Exhaust Valve Lash: 0.027" Cold
      • Cummins L10 (1985-1990)
        • Oil Pressure At Idle: 10 PSI Minimum
        • Oil Pressure: 30 PSI @ 1200 RPM or Peak Torque
        • Intake Valve Lash: 0.014" Cold
        • Exhaust Valve Lash: 0.027" Cold
      • Cummins QSM (1995-2015)
        • Oil Pressure At Idle: 10 PSI Min
        • Oil Pressure: 40-50 PSI @ Rated Speed
        • Intake Valve Lash: 0.014" Cold
        • Exhaust Valve Lash: 0.027" Cold
    • Includes:
      • (6) Cylinder Liner Kit
      • (12) Connecting Rod Bearing
      • (6) Piston Kit
      • (1) O-Ring Seal
      • (1) Oil Pan Gasket
      • (2) Lower Thrust Washer
      • (1) Main Bearing Set
      • (1) Upper Engine Gasket Set
    • Heavy Duty Engineered To Provide A Long Service Life
    • ISO 9001:2015 Certified With Design
    • AAR M-1003 Certified
    • Sold As A Kit
    • Quality Made Product

    Direct Aftermarket Replacement For OEM #s: 4090008, FP-4090008, FP4090008, ISM101-017, ISM101017, M-4090008, M4090008

    There may be multiple listings on our site that fit the same model engine but due to the technical nature of engine kits, the correct application and fitment is decided by engine serial #. If it is determined that you will need a different engine kit and there is a price difference, a member of our team will contact you to see if you still wish to proceed. We will do our best to make the buying process as easy as possible for you!

    Providing engine parts, fuel injection parts, and gaskets for the diesel and gas industries since 1947, Interstate-McBee strives to provide quality and consistency in their products while offering the most extensive selection in the aftermarket. Following a meticulous manufacturing and remanufacturing process using only the best possible raw materials, all products are guaranteed to be consistent with their industry-leading standards.

    Any mention of OEM names or OEM product ID numbers/descriptions/model numbers is intended for identification purposes only and does not indicate that it is an OEM part.

    California Prop 65 WARNING: This product may expose you to a chemical known to the State of California to cause cancer and birth defects or other reproductive harm

    If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990

    *This product ships LTL Freight and the shipping quotes are based on commercial addresses only. If you need a quote to have this delivered to a residential address or farm, please call us so we can provide you with an accurate shipping price. Failing to provide a commercial address could result in delays with processing your order. Please refer to our Shipping Info section at the bottom of our website for more information.

  • Warranty Information

    Interstate-McBee General Warranty Policies

    Engine Components and Kits: Warranted against manufacturing defects for one year (1 yr.) or 100,000 miles, whichever comes first.
    Fuel Injectors, Pumps, and Components: Warranted against manufacturing defects for one year (1 yr.)
