Holland Mark V Series Landing Gear

$1,371.95

SKU:
65814
Availability:
Ships out in 2-3 weeks
Shipping:
Calculated at Checkout

Holland Mark V Series Landing Gear

$1,371.95
SKU:
65814
Shipping:
Calculated at Checkout
Frequently bought together:
  • Description


    Holland Mark V Series Landing Gear

    The MARK V™ is the industry leader that will always deliver the strength, ease of operation, and the durability needed to exceed the demands of any landing gear application.

    • SAF-Holland Mark V Landing Gear
    • Lift Capacity: 62,500 lbs. At 100 ft. - lbs. Input Torque
    • Ultimate Load Capacity: 200,000 lbs.
    • Side-Load Capacity 32,000 lbs.
    • Gear Ratios vs. Turns Per Inch: Low Gear = 33.8, High Gear = 2.5
    • 80,000 PSI Minimum Yield Upper Housing And Retract Tube Strength
    • Superior Side-Load Capacity Of 32,000 lbs.
    • 2.5 Turns Per Inch Travel Makes It One Of The Fastest To The Ground And Back Up
    • Specially Designed To Shift Easily Even In Cold Weather
    • A Durable Performer, With Three Large, In-Line, Heat-Treated Ductile Iron Spur Gear
    • Large, Rolled, 1 5/8" Diameter Double Lead Elevating Screw Offers Added Strength And Smooth Lift
    • Gearbox With Low-Temperature, Premium Lube Rated For Service From -65°F To 225°F
    • Industry-Standard TTMA Mounting Plate
    • Black Armour Metal Treatment®
    • Double-D Crank Handle Connection For More Stabilized Cranking And Stronger Crank Connection
    • Guards Against Environmental Factors
    • Anti-Rust Protection
    • Long-Lasting And Reliable Retention Of Value
    • Sold Individually
    • Quality Made Product

    The BLACK ARMOUR® metal protection process chemically bonds with metal to form a protective skin that is impervious to water and anti-icing chemicals. BLACK ARMOUR® is paint compatible without pre-sanding. If scratched, BLACK ARMOUR® inhibits the spread of creep corrosion.

    This eco-friendly metal treatment provides remarkable protection without the added weight and cost of galvanization.

    If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990

  • Warranty Information
    The HOLLAND FW35 Series is guaranteed for 6-Years/600,000 Miles to provide maximum operation performance. In the unlikely case of wear requiring lock mechanism replacement, SAF-HOLLAND will cover the cost of parts, labor and freight.
  • Reviews
  • Questions & Answers

Description


Holland Mark V Series Landing Gear

The MARK V™ is the industry leader that will always deliver the strength, ease of operation, and the durability needed to exceed the demands of any landing gear application.

  • SAF-Holland Mark V Landing Gear
  • Lift Capacity: 62,500 lbs. At 100 ft. - lbs. Input Torque
  • Ultimate Load Capacity: 200,000 lbs.
  • Side-Load Capacity 32,000 lbs.
  • Gear Ratios vs. Turns Per Inch: Low Gear = 33.8, High Gear = 2.5
  • 80,000 PSI Minimum Yield Upper Housing And Retract Tube Strength
  • Superior Side-Load Capacity Of 32,000 lbs.
  • 2.5 Turns Per Inch Travel Makes It One Of The Fastest To The Ground And Back Up
  • Specially Designed To Shift Easily Even In Cold Weather
  • A Durable Performer, With Three Large, In-Line, Heat-Treated Ductile Iron Spur Gear
  • Large, Rolled, 1 5/8" Diameter Double Lead Elevating Screw Offers Added Strength And Smooth Lift
  • Gearbox With Low-Temperature, Premium Lube Rated For Service From -65°F To 225°F
  • Industry-Standard TTMA Mounting Plate
  • Black Armour Metal Treatment®
  • Double-D Crank Handle Connection For More Stabilized Cranking And Stronger Crank Connection
  • Guards Against Environmental Factors
  • Anti-Rust Protection
  • Long-Lasting And Reliable Retention Of Value
  • Sold Individually
  • Quality Made Product

The BLACK ARMOUR® metal protection process chemically bonds with metal to form a protective skin that is impervious to water and anti-icing chemicals. BLACK ARMOUR® is paint compatible without pre-sanding. If scratched, BLACK ARMOUR® inhibits the spread of creep corrosion.

This eco-friendly metal treatment provides remarkable protection without the added weight and cost of galvanization.

If you should need additional Truck Parts and Accessories, please don't hesitate to call our toll-free number 1-888-888-7990

View AllClose

Warranty Information

The HOLLAND FW35 Series is guaranteed for 6-Years/600,000 Miles to provide maximum operation performance. In the unlikely case of wear requiring lock mechanism replacement, SAF-HOLLAND will cover the cost of parts, labor and freight.
